General description
The Evolution R255DCT is a powerful 255mm (10-inch) electric disc cutter designed for cutting through various materials, including standard house bricks, concrete, and natural stone. With a nominal cutting depth of 102.5mm, it is ideal for tasks such as opening windows and doors in brickwork. The saw is equipped with the Evolution Premium Diamond blade, which contains 33% diamond and features a multi-compound cutting edge for faster and cleaner cuts. Its ergonomic design ensures ease of use and control, while the 2000W motor provides efficient cutting performance.Technical specifications
- Power: 2,000 / 1,600 Watt (240v / 110v)
- Rated Speed: 6000 RPM
- Max Duty Cycle: 20 Minutes
- Weight: 7.3 kg
- Cable Length: 4m / 13 ft Rubber Cable
- Nominal Cutting Capacity at 90°: 102.5 mm
- Blade Supplied: Premium Diamond Blade (PD255SEG-CS)
- Blade Diameter: 255 mm / 10 in.
- Blade Bore / Arbor: 22.2 mm
- Sound Pressure Max: 98.0 dB(A) K=3 dB(A)
- Sound Power Level Max: 109.0 dB(A) K=3 dB(A)
- Handle Vibration Max Level: 6.15 m/s² K=1.5 m/s²
Compatibility and accessories
- Compatible with R255DCT General Purpose Diamond Blade (D255SEG-CS)
- Compatible with R255DCT Premium Diamond Blade (PD255SEG-CS)
- Compatible with R255DCT Multi-Material Metal Cutting Blade (MD255SEG-CS)
- Compatible with Evolution Soft Shell Carry Tool Bag (012-0250)
Installation
For installation, refer to the user manual provided with the product. Ensure that the blade is securely attached and that all safety precautions are followed before use.
Usage
The R255DCT is designed for cutting various materials, including:
- Brickwork
- Concrete
- Reinforced concrete
- Natural stone
- Roof tiles
Utilize the built-in dust port for easy vacuum attachment to minimize dust during operation.
Other information
Features a double insulated motor coil for improved motor life and protection against dust ingress. The unique aerodynamic fan system enhances airflow for better cooling during heavy-duty use. Built-in drainage holes prevent water accumulation inside the machine.
